OVERVIEW
- Introduced January 2007 (Shipped June 2007)
- Discontinued September 2007 (4 GB) June 2008 (8 and 16 GB)
- Model Identifier iPhone1,1
- Model Number A1203
- Order Number MA501LL/A (4 GB), MA712LL/A (8 GB), MB384LL/A (16 GB)
- Support Status Vintage
- Colors Black
- Weight and Dimensions 4.8 ounces, 4.5 H x 2.4 W x 0.46 D inches
DISPLAY AND STORAGE
- Display Size 3.5-inch (diagonal) widescreen
- Display Resolution 320 by 480 pixels (160 or 163 ppi)
- Capacity 4, 8, or 16 GB
- Input Method Multi-Touch
PROCESSOR AND MEMORY
- Processor Samsung ARM 1176JZ(F)-S
- Processor Speed 620 MHz (running at 412 MHz)
- Architecture 32-bit
- Number of Cores 1
- Graphics Card PowerVR MBX Lite
- Built-in Memory 128 MB
SOFTWARE
- Original OS iOS 1.0 (1A543a)
- Maximum OS iOS 3.1.3 (7E18)
- iTunes Version iTunes 7.3 or later
- System Requirements Mac OS X v10.4.10 or later or Windows Vista Home Premium, Business, Enterprise, or Ultimate Edition; or Windows XP Home or Professional with Service Pack 2 or later
MEDIA
- Audio Formats AAC, Protected AAC, MP3, MP3 VBR, Audible (formats 1, 2, and 3), Apple Lossless, AIFF, and WAV
- Video Formats H.264 video, up to 1.5 Mbps, 640 by 480 pixels, 30 frames per second, Low-Complexity version of the H.264 Baseline Profile with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats; H.264 video, up to 768 Kbps, 320 by 240 pixels, 30 frames per second, Baseline Profile up to Level 1.3 with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats; MPEG-4 video, up to 2.5 Mbps, 640 by 480 pixels, 30 frames per second, Simple Profile with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats
SOFTWARE
- Original OS iOS 1.0 (1A543a)
- Maximum OS iOS 3.1.3 (7E18)
- iTunes Version iTunes 7.3 or later
- System Requirements Mac OS X v10.4.10 or later or Windows Vista Home Premium, Business, Enterprise, or Ultimate Edition; or Windows XP Home or Professional with Service Pack 2 or later
MEDIA
- Audio Formats AAC, Protected AAC, MP3, MP3 VBR, Audible (formats 1, 2, and 3), Apple Lossless, AIFF, and WAV
- Video Formats H.264 video, up to 1.5 Mbps, 640 by 480 pixels, 30 frames per second, Low-Complexity version of the H.264 Baseline Profile with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats; H.264 video, up to 768 Kbps, 320 by 240 pixels, 30 frames per second, Baseline Profile up to Level 1.3 with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats; MPEG-4 video, up to 2.5 Mbps, 640 by 480 pixels, 30 frames per second, Simple Profile with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats
CONNECTIONS AND SENSORS
- Ports 3.5-mm headphone jack, 30-pin dock connector
- Wi-Fi 802.11b/g
- Bluetooth Bluetooth 2.0+EDR
- Networks Quad-band GSM (850, 900, 1800, 1900 MHz)
- SIM slot mini-SIM
- Location None
- Sensors Proximity, ambient light, and Accelerometer
- Camera Built-in 2.0 megapixels
- Audio In Microphone
- Audio Out Built-in speaker
POWER
- Battery Built-in rechargeable lithium-ion battery (3.7 V at 1400 mAh)
- Battery Life Talk Time: Up to 8 hours Standby: Up to 250 hours Internet Use: Up to 6 hours Video playback: Up to 7 hours Audio playback: Up to 24 hours
- Power Adapter Apple 5W or 12W USB Power Adapter
ENVIRONMENTAL
- Operating Temperature 32° to 95° F
- Nonoperating Temperature −4° to 113° F
- Relative Humidity 5 percent to 95 percent noncondensing
- Maximum Operating Altitude 10,000 feet
HISTORY
Steve Jobs, CEO at Apple Inc., conceived an idea of using a multi-touch touchscreen to interact with a computer in a way in which he could type directly onto the display, essentially removing the physical keyboard and mouse, the same as a tablet computer. Jobs recruited a group of Apple engineers to investigate the idea as a side project. When Jobs reviewed the prototype and its user interface, he conceived a second idea of implementing the technology onto a mobile phone. The whole effort was called Project Purple 2 and began in 2005. The original iPhone was introduced by Steve Jobs on January 9, 2007 in a keynote address at the Macworld Conference and Expo held in Moscone West in San Francisco, California. In his address, Jobs said, "I have been looking forward to this for two and a half years", and that "today, Apple is going to reinvent the phone." Jobs introduced the iPhone as a combination of three devices: a "widescreen iPod with touch controls"; a "revolutionary mobile phone"; and a "breakthrough Internet communicator".
HISTORY PROVIDED BY WIKIPEDIA
Text is available under the Creative Commons Attribution-ShareAlike License
PROJECT NAME AND TAGLINE
- Project Name Purple 2, M68
- Tagline Introducing iPhone. Apple reinvents the phone.
